    Dry Powder Mineral Permanent Electro Magnetic Separator Equipment 20A600 For Feldspar,quartz,medicine

    Ask Lasest Price
    Brand Name : WDY
    Model Number : WG600-V-20
    Certification : ISO9001:2008
    Price : Negotiable
    Delivery Time : Within 20 days after the advance payment is made
    • Product Details
    • Company Profile

    Dry Powder Mineral Permanent Electro Magnetic Separator Equipment 20A600 For Feldspar,quartz,medicine


    Dry powder mineral permanent electromagnetic separator


    Dry Powder Mineral Permanent Electro Magnetic Separator Equipment 20A600 For Feldspar,quartz,medicine


    1> The Application Scope: Clean the low magnetic material to improve the material grade from the industrial mineral, ceramic, abrasive materials, plastic, silicon sand, medicine, glass, founding, building material, the special material ,metal and electronicproducts grade, resources recovery and so on.


    2> Structure

    Manufactured with rare earth magnet and Kevlar belt, the surface can be over 17000 Gs after belt. The separator can clean silica, sulfur dioxide, stainless steel (SUS 304) from the material. The demagnetization is no morethan 6% after 10 years. Used for 0.03-3mm material.

    The material also have flow arrangement according the the material dimension. The part flow system can be set on feeder or belt to confirm the material pass the strongest magnetic material to confirm the best purity.


    ModelWG160B-V-3WG220B-V-3WG300-V-7WG220B-V-11WG430-V-11WG220-V-15WG600-V-20
    Magnetic field strength(t)2233353
    Input voltage(VAC)380220380380380380380
    Maximun output current(A)1572020203040
    Maximum coil power(KW)33711111520
    Insulation categoryEEEEEEE
    Cooling methodwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil cooling
    Magnetic lumen diameter(mm)160220300220430220600
    Yield(m3/h)0.5-1.5438331.5-40.5-31.5-61-33-8
    Dimension(mm)700*700860*8601320*13201300*1101500*15001350*11001500*1500
    *1450*1540*2500*1800*2500*1850*2000
    Main machine weight(kg)45049010201130121015002000
    Usage60-300 mesh feedstock of iron elimination

    3> Technical parameter
