    Mineral Processing High Gradient Magnetic Separator Electromagnetic magnetic Separation Equipment

    Ask Lasest Price
    Brand Name : WANDAYE
    Model Number : WL1750T
    Certification : ISO9001:2008
    Price : Negotiable
    Delivery Time : Within 10 days after the advance payment is made
    • Product Details
    • Company Profile

    Mineral Processing High Gradient Magnetic Separator Electromagnetic magnetic Separation Equipment

    Feldspar,Quartz,Kaolin Magnetic Particle Separator Magnetic Iron Separator ISO


    Company profile


    Foshan Wandaye Machinery Company Limited is a national high-tech enterprise,owns a number of invention patents, with research and development production,major products are: magnetic separator for non-metallic mineral raw materials, ceramic glaze, metal, plastics, food and all kinds of industries.The main products are: electromagnetic Slurry separator, electromagnetic powder machine, permanent magnetic separator vertical ring electromagnetic separator,vertical ring permanent magnetic separator and different sizes of magnetic plates, magnetic rod, drawer type magnetic separator etc; Our company possesses professional technical team and sophisticated laboratory,can be customized for magnetic separator. Wandaye Limited since 2014 get involved in domestic and international mineral processing engineering technology and the fields of whole line project design etc .


    Product features


    Vertical ring magnetic separator coming over the technical problem that the magnetic media of high gradient flat ring magnetic separator is easy to block up.


    The separator possesses many advantages such as high magnetic field intensity, high gradient magnetic field, big concentration ratio, having a wide range in the particle size of feeding ore and the thickness of slurry, intelligent control operation, get a satisfactory mineral processing result when separate the low intensity magnetic ores.


    Operation process


    1. When mineral processing, firstly, filled the separation cavity with water, open the pulsating equipment, then feeding the raw ore from the feed box.

    2. The magnetic particle in the separation cavity separate from the non-magnetic particle by the different magnetic force, pulsating fluid force and gravity which those particles are acted on.

    3. The magnetic particles are absorbed on the magnetic media, the nonmagnetic particle will discharge from the iron discharge. several minutes later, magnetic cutting, then flushing the magnetic particle from the magnetic media.


    Application scope


    It is used to purify the non-metallic minerals and separate the low intensity magnetic minerals. The non-metallic minerals includes quartz, feldspar, nepheline, fluorite,spodumene,kaolin. The low intensity magnetic minerals includes hematite, limonite and tantalum-niobium ores.


    Technical parameter


    Model

    WD-1250

    WD-1500

    WL1750T

    WD-2000

    Swivel outer diameter(mm)

    1250

    1500

    1750

    2000

    Ore size(mm),

    (-200 mesh %)

    -1.2(30-100)

    -1.2(30-100)

    -1.2(30-100)

    -1.2(30-100)

    Ore density(%)

    10-40

    10-40

    10-40

    10-40

    Ore pulp transit capability(m³/h)

    20-50

    50-100

    75-150

    100-200

    Dry ore throughput(t/h)

    10-18

    20-30

    30-50

    50-80

    Rated background magnetic field(T)

    1.0

    1.0

    1.0

    1.0

    Rated energizing current(A)

    850

    950

    1200

    1200

    Rated energizing voltage(V)

    23

    29

    31

    35

    Rated exciting power(Kw)

    19

    27

    37

    40

    Swivel rotating power(Kw)

    1.5

    3

    4

    5.5

    Rotating pulsation power(Kw)

    2.2

    4

    4

    7.5

    Pulse stroke(mm)

    0-20

    0-30

    0-30

    0-30

    Pulse speed(times/min)

    0-300

    0-300

    0-300

    0-300

    Water consumption(Mpa)

    0.15-0.3

    0.2-0.3

    0.2-0.3

    0.2-0.3

    Water consumption(m³/h)

    30-45

    60-90

    80-120

    100-150

    Cooling water processing(m³/h)

    2.5-3

    3-4

    4-5

    5-6

    Weight of biggest parts(T)

    4

    5

    11

    14

    dimension(length x width x height,mm)

    3200x2340x2700

    3600x2900x3200

    3900x3300x3800

    4200x3550x4200
