    12 Layer Permanent Magnetic Separator Cabinet With Rare Earth Neodymium Magnets

    Ask Lasest Price
    Brand Name : WDY
    Model Number : 3 Layer Belt Conveyor Iron remover
    Certification : ISO9001:2008
    Price : Negotiable
    • Product Details
    • Company Profile

    12 Layer Permanent Magnetic Separator Cabinet With Rare Earth Neodymium Magnets

    Permanent Magnetic Separator Magnetic rod Cabinet for 12-layer can design by customers


    Product Characteristic


    The magnetic field area is large and the magnetic force is strong .

    The machine is durable .

    Low consumption and low fault rate.

    High yield and iron removal completely.


    Operation process


    1. The raw material flow into feeding entrance, then it land on the belt, through the belt conveyor to the magnetic roller.

    2. Then all iron material in the raw material adsorbed on the magnetic pole, last it follow the belt running to the non-magnetic area, and the iron material will automatically fall into the iron box.


    Technical parameter


    Product capacity(T)

    4-10

    Magnetic field intension(GS)

    15000

    Magnetic roller specification(mm)

    φ150 X 1200

    Power(KW)

    1.5

    Input voltage(V)

    380

    Motor rotation quantity(RPM)

    1390

    Belt rotation quantity(cycle/min)

    46


    Application scope


    Applicable for dry powder iron removal in ceramic industry, like quartz sand, refractory of non-metallic materials and the iron removal of Scrap metal.


    12 Layer Permanent Magnetic Separator Cabinet With Rare Earth Neodymium Magnets
