    Magnetic Separator Feedstock Separacion Equiment Feldspar Quartz Graphite Sand

    Ask Lasest Price
    Brand Name : WDY
    Model Number : WG160-B-V-3
    Certification : ISO9001:2008
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Delivery Time : Within 25 days after the advance payment is made
    Supply Ability : 50 SETS PER MONTH
    • Product Details
    • Company Profile

    Magnetic Separator Feedstock Separacion Equiment Feldspar Quartz Graphite Sand

    300 Mesh Magnetik Separator Feedstock Separacion Equiment , Separacion


    Magnetic Separator Feedstock Separacion Equiment Feldspar Quartz Graphite Sand

    Magnetic separators are designed to separate ferrous materials from non-magnetic materials. The ferrous materials are usually impurities of varying particle size (from the micron level upto large pieces of tramp iron) and their extraction either improves the purity level of a bulk product or protects sensitive machinery (crushers, blades et.c) Separation techniques are also used in metal recycling to sort ferrous from non-ferrous material and for conveying cans in canning factories.

    • Designed for maximum field strength and depth of magnetic field.
    • Extremely robust structure
    • Powerful, Oil-cooled electromagnet for 24hours continuous operation
    • All Unit feature Class “H” insulation levels.
    • Automatically removes ferrous from conveyed products.
    • Comes complete with a Control panel.
    • Extreme pulling power for fast moving processing materials
    • Choice mounting / suspension styles
    • Custom made units available upon request.
    • For removing ferrous from shredded, crushed materials, industrial wastes, mined products, construction & demolition wastes, recyclables, electronic scraps, wood chips, glass, mould sand, etc

    Technical parameter


    ModelWG160B-V-3WG220B-V-3WG300-V-7WG220B-V-11WG430-V-11WG220-V-15WG600-V-20
    Magnetic field strength(t)2233353
    Input voltage(VAC)380220380380380380380
    Maximun output current(A)1572020203040
    Maximum coil power(KW)33711111520
    Insulation categoryEEEEEEE
    Cooling methodwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil cooling
    Magnetic lumen diameter(mm)160220300220430220600
    Yield(m3/h)0.5-1.5438331.5-40.5-31.5-61-33-8
    Dimension(mm)700*700860*8601320*13201300*1101500*15001350*11001500*1500
    *1450*1540*2500*1800*2500*1850*2000
    Main machine weight(kg)45049010201130121015002000
    Usage60-300 mesh feedstock of iron elimination
