    Laboratory High Intensity Induced Roll Magnetic Separator For Ores ceramics slurry

    Ask Lasest Price
    Brand Name : ZT
    Model Number : WD-1.5A160
    Certification : ISO9001:2008
    Price : Negotiable
    Delivery Time : Within 25 days after the advance payment is made
    Supply Ability : 50 SETS PER MONTH
    • Product Details
    • Company Profile

    Laboratory High Intensity Induced Roll Magnetic Separator For Ores ceramics slurry

    Laboratory High Intensity Induced Roll Magnetic Separator For Ores


    Laboratory High Intensity
    Induced Magnetic Separator for ores


    The Model 1.5A160 is a laboratory magnetic separator or pilot plant dry high intensity magnetic separator, is designed to separate moderately or weakly magnetic materials. Results obtained from this small separator are scalable to predict performance from large production size high intensity magnetic separators. The feed particle size to be separated in this separator should range from 40-400 mesh.

    MAGNETIC FIELD CONTROL

    A specially designed circuit, utilizing a current to energize the field of the magnet. This field is continuously variable from 0 up to 25,000 gauss. A digital ammeter is used to provide precise current to the coil, and corresponding magnetic field strength.


    APPLICATIONS

    Glass Sands
    Calcite
    Monazite, Rare Earths
    Wollastonite
    Mica
    Zircon
    Barite
    Garnet
    Tantalite, Columbite
    Feldspar
    Rutile, Ilmenite
    Cassiterite


    Technical parameter


    Model

    1.5A160

    3A89

    3A190

    7A250

    7A300

    11A250

    18.5A250

    Magnetic field strength(T)

    2.5

    2.5

    2

    3

    3

    3.5

    3

    Input voltage(ACV)

    220

    380

    220

    380

    380

    380

    380

    Maximumoutput current(DCA)

    7

    7

    10

    18

    18

    20

    32

    Maximum coil power(KW)

    1.5

    3

    3

    7

    7

    11

    18.5

    Insulation method

    E

    E

    E

    E

    E

    E

    E

    Cooling method

    water and oil double cooling

    water and oil double cooling

    water and oil double cooling

    water and oil double cooling

    water and oil double cooling

    water and oil double cooling

    water and oil double cooling

    Magnetic lumen diameter(mm)

    160

    89

    190

    250

    300

    250

    250

    yield

    (m³/h)

    1-1.5

    0.2-0.5

    5-10

    10-25

    10-30

    10-25

    10-30

    dimension(mm)

    1200*1200

    *1850

    850*750*

    1000

    1000*950*

    1550

    1320*1200*

    1850

    1200*1200*

    1850

    1320*1200*

    1850

    1400*1400*

    1850

    Main machine weight(KG)

    180

    250

    510

    1050

    1070

    1210

    1500

    Usage

    Applicable for 40-400 mesh feedstock of iron elimination
