    Recycling Industries Magnetic Separation Equipment Method Separation Of Mixtures

    Ask Lasest Price
    Brand Name : ZT
    Model Number : WD-11A220S
    Certification : ISO9001:2008
    Price : Negotiable
    Delivery Time : Within 25 days after the advance payment is made
    Payment Terms : T/T, Western Union, L/C
    • Product Details
    • Company Profile

    Recycling Industries Magnetic Separation Equipment Method Separation Of Mixtures

    Recycling Industries Magnetic Separation Equipment Method Separation Of Mixtures

    Advantages:

    • Fields to magnetize the collecting elements can be matched to the separation requirements, from about 1 through 20 kilogauss in the empty separating space.
    • Large volumes of magnetized matrix spaces can be generated to meet processing needs.
    • Separating spaces can be filled with a virtually endless variety of matrix elements.
    • The magnetic field can be conveniently turned off to allow easy cleaning of the matrix, making it possible to automate the cleaning cycle.
    • Equipment can be designed to meet unusual processing conditions including high temperature, high pressure and many corrosive products.
    • Equipment is available for use in hazardous environments.

    Applications:
    • Coal Industries
    • Abrasive Industries
    • Chemical Industries
    • Paper and Pulp Industries
    • Ceramic Industries
    • Rubber Industries
    • Petroleum Industries
    • Animal Feed Industries
    • Recycling Industries
    • Mineral Processing
    Features:
    • Electromagnetic Separator have a deep penetrating magnetic field.
    • Electromagnetic Separator needs low maintenance and are easy to install and operate.
    • Electromagnetic Separator can function smoothly even in the hazardous environments.
    • No manual cleaning is required and reduces downtime for the end user.

    Technical parameter:

    Model3A1603A2207A300

    11A220

    11A43015A22020A600
    Magnetic field strength(t)2233353
    Input voltage(VAC)380220380380380380380
    Maximun output current(A)1572020203040
    Maximum coil power(KW)33711111520
    Insulation categoryEEEEEEE
    Cooling methodwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil coolingwater and oil cooling
    Magnetic lumen diameter(mm)160220300220430220600
    Yield(m3/h)0.5-1.51-31.5-40.5-31.5-61-33-8
    Dimension(mm)

    700*700

    *1450

    860*860

    *1540

    1320*1320

    *2500

    1300*110

    *1800

    1500*1500

    *2500

    1350*1100

    *1850

    1500*1500

    *2000

    Main machine weight(kg)45049010201130121015002000
    Usage60-300 mesh feedstock of iron elimination
